連接示意圖
Schematic diagram of connection |
 |
單力矩螺母
Single-torque nut |
 |
雙力矩螺母
Double-torque nut | |
| 一、產品概述 Genera |
1. 用于從低壓架空裸線（銅或鋁）支接到絕緣導線（銅或鋁）。
2. 主線：架空銅或鋁裸線 3. 支線：絕緣銅或鋁
4. 穿刺線夾主體采用高強度，抗機械變化和氣候變化的絕緣材料制成。
5. 緊固螺釘經抗腐蝕處理，并配有緊固力矩螺母，使安裝更簡便、安全、快捷，恒定穿刺壓力可確保穿刺線夾達到需要的電氣效果。
6. 絕緣穿刺接觸（用中性油脂）在支接側搭接，按不同型號用以下材料制成：
——鋁合金（AF型） ——銅合金（F型） —— 鍍錫銅合金（EF型）
7. 采用密封防水結構的支線端蓋，可防止水侵入支接導線，可根據需要左側或右側分支
1. Used for branch connection of LV aerial bare line (copper or aluminum) to insulated conductor (copper or aluminum).
2. Main line: Aerial copper or aluminum bare line
3. Branch line: Insulated copper or aluminum
4. Main body of connector is made of high strength insulating material that anti mechanical change or climatic variation.
5. The screw is anticorrosion treated, and is equipped with fastening torque nut, the torque nut enables the installation to be much simple, safe and quick, its constant puncturing pressure guarantees best electrical effect for connector.
6. The insulating puncture contact (applies neutral lipids) is lap jointed on the branch connection side, is made of the following material according to different models: —— Aluminum alloy (AF type) ——Copper alloy (F type) ——Tin-copper alloy (EF type)
7. End cap of branch line adopts waterproof sealing structure, it prevents water from entering into the branch connected conductor. It can be branched on the left or right side according to the demand. |
 |
 |
力矩螺母
Torque nut |
分支可左可右
The branch can be on the left or right side. | | |
